Well Casing & Tubing

Out Diameter: 1.315" - 20".

Wall Thickness: 0.133" - 0.500".

Length: R1(group1), R2(group2), R3(group3).

Materials & Grades: J55, K55, N80, L80, P110.

Application: oil well extracting, borehole, borewell.

Types: Seamless Casing, ERW Casing.

Stock: 10000 Ton/Month.

Delivery: Within 10 days after deposit.

Payment: TT, LC, D/P.

Packing: Bare of Bundled or pvc packing or for the client's requiremen.

Usage: For conveying gas, water and oil either in the oil or natural gas industries.

Contact us: +86 13093037157.

Send E-mail

Whatsapp/Wechat

PRODUCT DESCRIPTION

Types:

Seamless Casing

ERW Casing

Connections:

P (Plain end)

STC (short threads)

LTC (long threads)

BTC (buttress threads)

Premium gas-tight connectors

Non-upset ends (NUE)

External upset ends (EUE)

Premium gas-tight connectors

Others special connectors

CHEMICAL COMPOSITIONS OF CASING PIPE

Standard	Grade	Chemical compositions（％）
API SPEC 5CT	J55	C	Si	Mn	P	S	Cr	Ni	Cu	Mo	V
	K55	0.34～0.39	0.20～0.35	1.25～1.50	≤0.020	≤0.015	≤0.15	≤0.20	≤0.20	/	/
	N80	0.34～0.38	0.20～0.35	1.45～1.70	≤0.020	≤0.015	≤0.15	/	/	/	0.11～0.16
	L80	0.15～0.22	≤1.00	0.25～1.00	≤0.020	≤0.010	12.0～14.0	≤0.20	≤0.20	/	/
	P110	0.26～0.395	0.17～0.37	0.40～0.70	≤0.020	≤0.010	0.80～1.10	≤0.20	≤0.20	0.15～0.25	≤0.08

MECHANICAL PROPERTIES OF CASING PIPE

Grade	Type	Total elongation	Yield strength	Yield strength	Tensile strength	Hardness	Hardness
		under load	(min)Mpa	(max)Mpa	min Mpa	Max (HRC)	Max (HBW)
		(%)
J55	-	0.5	379	552	517	-	-
K55	-	0.5	379	552	655	-	-
N80	1	0.5	552	758	689	-	-
N80	Q	0.5	552	758	689	-	-
L80	1	0.5	552	655	655	23	241
L80	9Cr	0.5	552	655	655	23	241
L80	13Cr	0.5	552	655	655	23	241
C90	-	0.5	621	724	689	25.4	255
C95	-	0.5	655	758	724	-	-
T95	-	0.5	655	758	724	25.4	255
P110	-	0.6	758	965	862	-	-
Q125	All	0.65	862	1034	931	-	-

CASING PIPE MANUFACTURING PROCESS

Steel ingot heating → hydraulic punching → reheating → extension → periodic rolling → reheating → sizing → cooling → straightening → pipe cutting → inspection

1. An annular heating furnace is required for ingot heating;

2. Punching and reheating with hydraulic press;

3. The oil casing plant uses a two-roller guide plate extension machine for extension;

4. Re-use a disc heating furnace for periodic rolling, and use a non-entry furnace for reheating, cooling, straightening, pipe cutting, and inspection.

TEST METHOD

Our products are of high quality and are thoroughly inspected before shipping.

PRODUCT ADVANTAGES

1.We are factory, our carbon pipe price is lower than 99% of other suppliers.

2.Large storage capacity, fast delivery.

3.Complete specifications, we basically have the goods you need in stock.

4.Strictly control product quality to ensure that customers receive high-quality products.

5.Support product customization.

6.More than 15 years of foreign trade experience, customers in more than 50 countries.

7.Support any third-party inspection before shipment.

OUR FACTORY

SHAANXI JINYOU METAL TECHNOLOGY CO., LTD is a a manufacturer of stainless steel and carbon steel product. We have well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in mechanical manufacturing , metallurgical minerals , building materials, shipping, aircraft, automobile and other industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. We have an absolute advantage in the stainless steel and carbon steel industry.

We have imported equipment, professional masters, 48 production lines with high production efficiency and complete specifications. We have more than 10,000 tons of inventory per month, and the delivery speed is very fast. For products in stock, it can be shipped within 5 days. We support product customization, and the delivery time of customized products will not exceed a month. Customer satisfaction is the basis of our service. If you need our products, please contact our professional sales as soon as possible. We give you the most professional and reasonable quotation.

OUR HONORS AND CERTIFICATES

Our products go through strict quality inspection and can pass any third party test
